Запчасти Komatsu PC228US-3-AP ЦИЛИНДР КОВША (BLUE)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX210

CYLINDER GROUP,(FINAL COATING)

|1

707-01-0C890

CYLINDER ASS'Y

1

707-13-11560

CYLINDER

2

20Y-70-21230

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

707-58-80651

ROD,PISTON

5

22U-70-21260

BUSHING

6

20Y-70-23220

SEAL,DUST (KIT)

7

707-27-11981

HEAD,CYLINDER

8

07179-13094

RING,SNAP

9

195-63-92190

SEAL,DUST (KIT)

10

707-52-90560

BUSHING

11

707-51-80030

PACKING,ROD (KIT)

12

07000-15105

O-RING (KIT)

13

707-35-91150

RING,BACK-UP (KIT)

14

707-51-80640

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-11851

PISTON

18

707-44-11280

RING,PISTON (KIT)

19

707-39-11530

RING,WEAR (KIT)

20

707-44-11920

RING

21

707-35-90360

RING (KIT)

22

07000-15070

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00000

FITTING,GREASE

26

707-86-66280

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING (KIT)

30

707-88-22570

BRACKET

31

707-88-21271

BAND

32

01435-01030

BOLT

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

|K

707-99-45230

SERVICE KIT
