Запчасти Komatsu PC228US-3-AG БЛОК КОНДИЦИОНЕРА (/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22B-979-1660

AIRCON UNIT A.

1

TW534136-9221

CASE ASS'Y

2

TW534461-8802

COVER

3

TW536021-6501

WIRING HARNESS

4

TW592024-3100

CLIP

5

TW592022-3700

SCREW

6

TW595327-8100

CLIP

7

TW592022-3700

SCREW

8

TW580534-0400

CLIP

9

TW582623-8500

SENSOR

10

TW534102-6000

BRACKET

11

TW012514-1640

TAPPING SCREW

12

TW582623-1800

SENSOR

13

TW580529-7000

CLIP

14

TW012155-1440

SCREW

15

TW583032-2300

INSULATOR

|16

TW582594-3020

RELAY ASS'Y

16

TW534104-8400

BRACKET

17

TW593111-8800

RELAY ASS'Y

18

TW593230-1420

RELAY ASS'Y

19

TW580140-0600

SCREW

20

TW582670-2501

POWER TRANSISTOR

21

TW012514-1640

TAPPING SCREW

22

TW534232-2200

SEAL

23

TW502700-2520

HEATER CORE ASS'Y

24

TW580534-4300

CLIP

25

TW592022-3700

SCREW

26

TW524120-1720

PLATE ASS'Y

27

TW534270-8321

DOOR

28

TW534470-9100

LEVER

29

TW580521-6800

CLIP

30

TW592055-0900

CLIP

31

TW536160-2201

ROD

32

TW012514-1640

TAPPING SCREW

33

TW534189-9200

LINING

34

TW534280-1400

SHAFT

35

TW020046-3540

BOLT
