Запчасти Komatsu PC228US-3-AG ЦИЛИНДР РУКОЯТИ(BLUE)(№-7) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9260

CYLINDER GROUP,(STRATO BLUE)

|1

22U-63-02623

CYLINDER ASS'Y

1

22U-63-62742

CYLINDER

2

20Y-70-21360

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

22U-63-62721

ROD,PISTON

5

707-27-13961

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90720

BUSHING

9

707-51-95030

PACKING,ROD (KIT)

10

07000-15125

O-RING (KIT)

11

707-35-91370

RING,BACK-UP (KIT)

12

707-51-95640

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13731

PISTON

16

707-44-13280

RING,PISTON (KIT)

17

707-39-13510

RING,WEAR (KIT)

18

707-44-13920

RING

19

707-71-61040

PLUNGER

20

07000-15085

O-RING (KIT)

21

707-35-90960

RING,BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-70250

PLUNGER

24

07020-00000

FITTING,GREASE

25

707-71-32770

COLLAR

26

707-35-91370

RING,BACK-UP (KIT)

27

07000-15125

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

29A

707-83-13010

VALVE

29B

07750-01628

SPRING

29C

707-87-14070

PLUG

29D

07002-12034

O-RING (KIT)

30

205-63-61171

TUBE

31

20D-62-17860

ELBOW

32

01435-01055

BOLT

33

01435-01040

BOLT

34

07000-13030

O-RING (KIT)

35

01010-81080

BOLT

36

01643-31032

WASHER

37

07000-13035

O-RING (KIT)

38

22U-63-62791

BRACKET

39

707-88-21260

BAND

40

01010-81035

BOLT

41

01643-51032

WASHER

42

707-88-11560

PLATE

43

07283-22738

CLIP

44

01599-01011

NUT

45

01643-31032

WASHER

|46

707-99-57180

SERVICE KIT
