Запчасти Komatsu PC228US-2J КАБИНА (ДВЕРЬ РОЛИК И STRIKER) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC228US-2J - КАБИНА (ДВЕРЬ РОЛИК И STRIKER) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
16
17
17
17
18
18
18
19
19
19
20
21
22
23
24

Артикул

Название

Примечание

Количество

|$8

22B-54-00021

CAB ASS'Y

|$9

22B-54-00020

CAB ASS'Y

|$10

22B-54-00041

CAB ASS'Y,(WITH FULL GUARD)

|$11

22B-54-00040

CAB ASS'Y,(WITH FULL GUARD)

|$12

22U-54-00131

CAB ASS'Y,(FOR U.S.A.)

|$13

22U-54-00130

CAB ASS'Y,(FOR U.S.A.)

|$14

22U-54-00141

CAB ASS'Y,(WITH FULL GUARD) (FOR U.S.A.)

|$15

22U-54-00140

CAB ASS'Y,(WITH FULL GUARD) (FOR U.S.A.)

|$16

22B-54-00031

CAB ASS'Y,(WITH HALF GUARD)

|$17

22B-54-00030

CAB ASS'Y,(WITH HALF GUARD)

|$18

22B-54-00181

CAB ASS'Y,(WITH HALF GUARD) (FOR U.S.A.)

|$19

22B-54-00180

CAB ASS'Y,(WITH HALF GUARD) (FOR U.S.A.)

|$20

22B-54-00291

CAB ASS'Y,(EU SPEC.)

|$21

22B-54-00290

CAB ASS'Y,(EU SPEC.)

|$22

22B-54-00311

CAB ASS'Y,(WITH FULL GUARD) (EU SPEC.)

|$23

22B-54-00310

CAB ASS'Y,(WITH FULL GUARD) (EU SPEC.)

|$24

21J-54-00072

DOOR ASS'Y

|$25

21J-54-00070

DOOR ASS'Y

1

21J-54-16630

GRIP

2

01220-40512

SCREW

3

01601-20513

WASHER

4

21J-54-16962

ROLLER ASS'Y

4

21J-54-16961

ROLLER ASS'Y

5

01010-80816

BOLT

6

01643-30823

WASHER

7

20U-54-24923

ROLLER ASS'Y

7

20U-54-24921

ROLLER ASS'Y

8

01010-80816

BOLT

9

01643-30823

WASHER

10

21J-54-18381

ROLLER ASS'Y

10

21J-54-18380

ROLLER ASS'Y

11

01010-80816

BOLT

12

01643-30823

WASHER

13

20U-54-25261

BRACKET

14

01010-81225

BOLT

15

01643-31232

WASHER

16

20U-54-25321

STRIKER

17

01010-80610

BOLT

18

01641-50608

WASHER

19

20U-54-25341

SHIM, 1.0MM

20

01580-10605

NUT

21

01643-30623

WASHER

22

21J-54-14912

PLATE

23

01010-81225

BOLT

24

01643-31232

WASHER

Выбрано товаров: 45
