Запчасти Komatsu PC228US-2 КЛАПАН ПЕРЕГРУЗКИ (ДЛЯ ЦИЛИНДРА СТРЕЛЫ) (ДЛЯ ЕС)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

702-21-08090

PILOT VALVE

1

BODY,VALVE

2

SPOOL

3

702-21-38510

CASE

4

702-21-38420

RETAINER, 2.0MM

4

702-21-38550

RETAINER, 1.7MM

4

702-21-38560

RETAINER, 2.3MM

4

702-21-38610

RETAINER, 1.8MM

4

702-21-38620

RETAINER, 1.9MM

4

702-21-38630

RETAINER, 2.1MM

4

702-21-38640

RETAINER, 2.2MM

5

702-21-38430

FLANGE

6

702-21-38440

SPRING

7

702-21-38650

SPRING

8

702-21-38460

O-RING

9

702-21-38470

O-RING

10

702-21-38480

PLUG

11

01252-60825

BOLT

12

01252-60835

BOLT

13

01252-60620

BOLT

14

01641-20608

WASHER

15

07000-12021

O-RING

16

709-74-92810

VALVE

17

709-75-92220

SPRING

18

700-93-11320

O-RING

19

700-93-11330

RING,BACK-UP

|$28

709-70-76100

VALVE ASS'Y,RELIEF

20

SLEEVE

21

700-80-64220

RING

22

700-22-11410

O-RING

23

SEAL

24

POPPET

25

PISTON

26

SPRING

27

SEAL

28

709-25-11390

O-RING

29

POPPET

30

O-RING

31

PLUG

32

NUT

33

NUT

34

SPRING

35

O-RING

36

SPACER
