Запчасти Komatsu PC228US-2 ЦИЛИНДР СТРЕЛЫ(ДЛЯ ЕС)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9200

CYLINDER GROUP,L.H.

G-2

22U-63-X9210

CYLINDER GROUP,R.H.

|$3

22U-63-02450

CYLINDER ASS'Y

1

22U-63-52342

CYLINDER

2

707-76-70630

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

22U-63-52323

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85630

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12071

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12110

RING,WEAR (KIT)

20

707-44-12911

RING

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

22U-63-52371

TUBE,L.H.

24

22U-63-52471

TUBE,R.H.

25

01435-01055

BOLT

26

01435-01040

BOLT

27

07000-13030

O-RING (KIT)

28

22U-63-52391

BRACKET,L.H.

28

22U-63-52491

BRACKET,R.H.

29

707-88-96530

BAND

30

01010-81035

BOLT

31

01643-51032

WASHER

32

07283-22738

CLIP

33

01599-01011

NUT

34

01643-31032

WASHER

|$41

707-98-46220

SERVICE KIT
