Запчасти Komatsu PC228US-2 ПЕРЕДН. КРЫШКА(COVER) (/) ( АКТУАТОР) (ДЛЯ ЕС)(№-) ЧАСТИ КОРПУСА

|$2

22U-54-17570

COVER

1

COVER

2

22U-54-11161

LOCK

3

22U-54-17590

SHEET

4

22U-54-12870

SEAL

5

01010-81230

BOLT

6

175-54-34170

WASHER

7

22U-54-15160

CAP

8

22U-54-12490

COVER

|$12

22U-54-15631

COVER

|$13

22U-54-15630

COVER

9

COVER

10

22U-54-11911

SEAL

11

22U-54-11991

SEAL

12

22U-54-15930

SHEET

13

22U-54-15940

SHEET

14

22U-54-15640

SEAL

15

22U-54-15650

SEAL

16

20Y-54-27503

LOCK ASS'Y

16

20Y-54-27502

LOCK ASS'Y

17

01010-81025

BOLT

18

01643-31032

WASHER

19

22U-54-11182

ROD

20

01643-31032

WASHER

21

04050-13020

PIN

22

22U-54-12250

BRACKET

23

01010-81230

BOLT

24

01643-31232

WASHER

25

01010-81230

BOLT

26

01643-31232

WASHER

27

175-54-34170

WASHER

28

22U-54-18190

CAP

29

22U-54-12170

BRACKET

30

01010-81230

BOLT

31

01643-31232

WASHER

32

22U-54-18180

CAP

33

22U-54-17650

COVER

34

22U-54-12980

SHEET

35

22U-54-12990

SHEET

36

08037-03614

GROMMET

37

01010-81230

BOLT

38

01643-31232

WASHER

39

175-54-34170

WASHER

40

22U-54-17620

BRACKET

41

01010-81225

BOLT

42

01643-31232

WASHER
