Запчасти Komatsu PC228US-1-TN TRAVAL МОТОР (МОТОР В СБОРЕ) (GM8VL ТИП) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22U-60-12510

MOTOR

|1

TZ684B400002-D

MOTOR

|1

TZ684B410002-D

FLANGE ASS'Y

|1

TZ684B410102-D

FLANGE KIT

1

FLANGE

2

SPOOL

3

PISTON

4

TZ100A2021-00

PLUG

5

TZ100A2051-00

PLUG

6

TZ671B405200-A

STOPPER

7

TZ120F2053-00

PLUG

8

TZ120F2054-00

VALVE

9

TZ100A2055-00

SPRING

10

TZ120F2055-00

SPRING

11

07000-13032

O-RING (K1)

12

07000-13022

O-RING (K1)

13

TZ512B2021-00

PLUG

14

TZGDL-1-16-S

PLUG

15

07000-12018

O-RING (K1)

16

TZ610B2021-00

PLUG

17

07000-12011

O-RING (K1)

18

07000-12014

O-RING (K1)

19

TZ678B4069-00

SPOOL

20

TZ678B4089-00

SPRING

21

04260-00952

BALL

22

07002-12034

O-RING (K1)

23

TZ263B2079-01

FILTER

24

TZ810B2021-00

PLUG

25

TZ682B4082-00

PLUG

26

07000-11005

O-RING (K1)

27

07000-11008

O-RING (K1)

28

TZJB1501-7

BALL

29

TZS0807

ORIFICE

30

GM-1-8-S

PLUG

31

TZ850A0006-00

PLATE¤ NAME

32

07042-20108

PLUG

33

TZJB1354-6-14

PIN

34

01252-41640

BOLT

K1

TZ695B9000-00

SERVICE KIT

|K

07000-11008

O-RING

|K

07000-05230

O-RING

|K

07000-05335

O-RING

|K

207-27-61330

RING

|K

07000-12018

O-RING

|K

TZOS-385811

SEAL

|K

TZ671B4035-00

O-RING

|K

TZ671B4039-00

O-RING

|K

07000-12016

O-RING

|K

07000-12022

O-RING

|K

07001-02016

RING

|K

TZJB2407T2-P22

RING

|K

07000-13029

O-RING

|K

TZSPGO-10H

SEAL

|K

07000-13032

O-RING

|K

07000-13022

O-RING

|K

07000-12018

O-RING

|K

07000-12011

O-RING

|K

07000-12014

O-RING

|K

07002-12034

O-RING

|K

07000-11005

O-RING
