Запчасти Komatsu PC228US-1-TN TRAVAL МОТОР (МОТОР В СБОРЕ) (GM8VL ТИП) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22U-60-12510

MOTOR

|1

TZ671B200000-T

MOTOR

|1

TZ671B2205-00

CYL. AND PISTON KIT

|1

PISTON KIT

|1

PISTON ASS'Y

1

PISTON

2

SHOE

3

CYLINDER BLOCK

4

PLATE

5

BOWL

6

WASHER

7

WASHER

8

SPRING

9

RING

10

BEARING

|11

TZ401B207000-A

PISTON ASS'Y

11

PISTON

12

SHOE

13

TZ671B2002-00

SHAFT

14

TZ671B200301-T

PLATE

15

TZ671B2009-01

PLATE

16

TZ671B4012-02

PISTON

17

TZ671B4013-00

SPRING

18

TZ671B4015-00

PLATE

19

TZ120F2016-00

PLATE

20

TZOS-385811

SEAL (K1)

21

TZ671B4035-00

O-RING (K1)

22

TZ671B4039-00

O-RING

23

TZ671B2048-00

BEARING

24

TZ671B2049-00

BEARING

25

TZ671B2076-02

PIVOT

26

TZ671B2077-01

PIN

27

TZ401B2093-00

SPRING

|28

TZ696B3000-00

VALVE

|28

TZ671B3000-03

VALVE

|28

TZ696B3100000B

VALVE KIT

|28

TZ671B3100030A

VALVE KIT

28

VALVE

|28

VALVE

29

SLEEVE

30

RETAINER

31

PLUG

32

SHIM

33

SPRING

34

O-RING (K1)

35

O-RING (K1)

36

O-RING (K1)

37

RING (K1)

38

RING (K1)

39

O-RING (K1)

40

SEAL (K1)
