Запчасти Komatsu PC228US-1-TN АККУМУЛЯТОР (NX)(№-8) ЭЛЕКТРИКА

1

207-06-11790

BATTERY¤ WET

2

08000-0000

3

08000-00001

TERMINAL¤ (-)

4

22U-06-11141

CLAMP

5

113-15-21251

BOLT

6

08038-42511

CAP

|6

08038-22511

CAP

7

08038-42511

CAP

8

08028-63125

CABLE

|8

08028-43125

CABLE

9

08028-63090

CABLE

|9

08028-43090

CABLE

10

08038-42511

CAP

11

08038-06031

CAP

12

22U-06-12161

BRACKET

13

01010-81230

BOLT

14

01643-31232

WASHER

15

22U-06-11151

CLAMP

|16

22U-06-11181

CUSHION

16

01010-81025

BOLT

17

01643-31032

WASHER

18

08036-01414

CLIP

19

01010-81025

BOLT

20

01643-31032

WASHER

21

22U-06-11181

CUSHION

22

22U-06-11170

COVER

23

01434-10820

BOLT¤ WING

24

01643-30823

WASHER

25

22U-06-12180

HOLDER

26

08006-30240

BOLT

27

01580-11008

NUT

28

01643-31032

WASHER

29

22U-06-11970

CLAMP

30

01010-81230

BOLT

31

01643-31232

WASHER

32

22U-06-11980

BRACKET

33

01010-81235

BOLT

34

01643-31232

WASHER
