Запчасти Komatsu PC228US-1-TN ПЕРЕДН. КРЫШКА(COVER) (/)(№-) ЧАСТИ КОРПУСА

|1

22U-54-17570

COVER

1

COVER

2

22U-54-11161

LOCK

3

22U-54-17590

SHEET

4

22U-54-12870

SEAL

5

01010-81230

BOLT

6

175-54-34170

WASHER

7

22U-54-17780

CAP

8

22U-54-12490

COVER

|9

22U-54-12395

COVER

|9

22U-54-12394

COVER

9

COVER

10

22U-54-11911

SEAL

11

22U-54-11991

SEAL

12

22U-54-12782

SHEET

13

22U-54-12791

SHEET

14

22U-54-12890

SEAL

15

20Y-54-27503

LOCK ASS'Y

|15

20Y-54-27502

LOCK ASS'Y

16

01010-81025

BOLT

17

01643-31032

WASHER

18

22U-54-11182

ROD

19

01643-31032

WASHER

20

04050-13020

PIN

21

22U-54-12250

BRACKET

22

01010-81230

BOLT

23

01643-31232

WASHER

24

22U-54-11861

BRACKET

25

01010-81220

BOLT

26

01643-31232

WASHER

27

01010-81230

BOLT

28

01643-31232

WASHER

29

175-54-34170

WASHER

30

22U-54-17790

CAP

31

22U-54-12170

BRACKET

32

01010-81230

BOLT

33

01643-31232

WASHER

34

22U-54-17430

CAP

|35

22U-54-17300

COVER

35

COVER

36

22U-54-12980

SHEET

37

22U-54-12990

SHEET

38

08037-03614

GROMMET

39

01010-81230

BOLT

40

01643-31232

WASHER

41

175-54-34170

WASHER

42

22U-54-12271

BRACKET

43

01010-81225

BOLT

44

01643-31232

WASHER
