Запчасти Komatsu PC228US-1 TRAVAL МОТОР (МОТОР В СБОРЕ) (GM8VL ТИП) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

22U-60-12510

MOTOR

|1

TZ695B1000-00

FINAL DRIVE ASS'Y

1

TZ684B1001-01

HUB

|1

SPINDLE KIT

|1

SPINDLE ASS'Y

2

SPINDLE

3

FLANGE

4

BOLT

5

PIN

6

WASHER

|7

RV GEAR ASS'Y

|7

RV GEAR KIT

7

RV GEAR

8

RV GEAR

9

SHAFT

10

SPACER

11

BEARING

12

BEARING

13

TZ671B1006-01

GEAR

|14

TZ671B1107-01

SPUR GEAR KIT

14

SPUR GEAR

15

TZ671B1008-03

COVER

16

TZ671B1013-02

PIECE

17

TZ50F1024-00

COUPLING

18

TZ671B1017-00

PIN

19

04065-09530

RING

20

TZ671B1021-00

BEARING

21

04064-04018

RING

22

07000-11008

O-RING (K1)

23

07000-05230

O-RING (K1)

24

07000-05335

O-RING (K1)

|25

170-27-00114

SEAL RING ASS'Y (K1)

25

RING

|25

RING

26

TZ610B2021-00

PLUG

27

TZJB1176M12-32

BOLT

28

04260-01111

BALL

29

TZ671B2077-01

PIN

30

07000-12018

O-RING (K1)
