Запчасти Komatsu PC228US-1 ЦИЛИНДР СТРЕЛЫ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

22U-63-X9110

CYLINDER GROUP,L.H. (NATURAL YELLOW)

G-1

22U-63-X2302

CYLINDER GROUP,L.H. (NATURAL YELLOW)

G-1

22U-63-X9080

CYLINDER GROUP,L.H. (VIOLET BLUE)

G-1

22U-63-X2350

CYLINDER GROUP,L.H. (VIOLET BLUE)

G-2

22U-63-X9120

CYLINDER GROUP,R.H. (NATURAL YELLOW)

G-2

22U-63-X2312

CYLINDER GROUP,R.H. (NATURAL YELLOW)

G-2

22U-63-X9090

CYLINDER GROUP,R.H. (VIOLET BLUE)

G-2

22U-63-X2360

CYLINDER GROUP,R.H. (VIOLET BLUE)

|1

22U-63-02203

CYLINDER ASS'Y

1

22U-63-52342

CYLINDER

2

205-70-71360

BUSHING

3

07145-00070

SEAL,DUST (KIT)

4

22U-63-52323

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-12921

HEAD,CYLINDER

8

07179-13099

RING,SNAP

9

707-56-85510

SEAL,DUST (KIT)

10

707-52-90610

BUSHING

11

707-51-85030

PACKING,ROD (KIT)

12

07000-15110

O-RING (KIT)

13

707-35-91220

RING,BACK-UP (KIT)

14

707-51-85630

RING,BUFFER (KIT)

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-12071

PISTON

18

707-44-12180

RING,PISTON (KIT)

19

707-39-12110

RING,WEAR (KIT)

20

707-44-12911

RING

21

07000-15075

O-RING (KIT)

22

707-35-90930

RING,BACK-UP (KIT)

23

01310-01216

SCREW

24

22U-63-52371

TUBE,L.H.

|24

22U-63-52471

TUBE,R.H.

25

22U-63-52380

TUBE,L.H.

|25

22U-63-52480

TUBE,R.H.

26

01435-01055

BOLT

27

01435-01040

BOLT

28

07000-13030

O-RING (KIT)

29

22U-63-52391

BRACKET,L.H.

|29

22U-63-52491

BRACKET,R.H.

30

707-88-96530

BAND

31

01010-81035

BOLT

32

01643-51032

WASHER

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

|36

707-98-46220

SERVICE KIT
