Запчасти Komatsu PC228US-1 ПЕРЕДН. КРЫШКА(COVER) (/) ( АКТУАТОР) (ДЛЯ MONO-СТРЕЛА) ЧАСТИ КОРПУСА

|1

22U-54-12384

COVER

1

COVER

2

22U-54-11161

LOCK

3

22U-54-12762

SHEET

4

22U-54-12870

SEAL

5

01010-81230

BOLT

6

175-54-34170

WASHER

7

22U-54-15160

CAP,(FOR U.S.A.)

|7

22U-54-11331

CAP

8

01010-81230

BOLT

9

21N-30-11340

COLLAR

10

01643-31232

WASHER

11

22U-54-12490

COVER

|12

22U-54-12394

COVER

12

COVER

13

22U-54-11911

SEAL

14

22U-54-11991

SEAL

15

22U-54-12782

SHEET

16

22U-54-12791

SHEET

17

22U-54-12890

SEAL

18

20Y-54-27502

LOCK ASS'Y

19

01010-81025

BOLT

20

01643-31032

WASHER

21

22U-54-11182

ROD

22

01643-31032

WASHER

23

04050-13020

PIN

24

22U-54-12250

BRACKET

25

01010-81230

BOLT

26

01643-31232

WASHER

27

22U-54-11861

BRACKET

28

01010-81220

BOLT

29

01643-31232

WASHER

30

01010-81230

BOLT

31

01643-31232

WASHER

32

175-54-34170

WASHER

33

09415-02512

CAP,(FOR U.S.A.)

|33

22U-54-11390

CAP

34

22U-54-12170

BRACKET

35

01010-81230

BOLT

36

01643-31232

WASHER

|37

22U-54-12911

COVER

37

COVER

38

22U-54-11940

SEAL

39

22U-54-11950

SEAL

40

22U-54-12980

SHEET

41

22U-54-12990

SHEET

42

08037-03614

GROMMET

43

01010-81230

BOLT

44

01643-31232

WASHER

45

175-54-34170

WASHER

46

22U-54-12271

BRACKET

47

01010-81225

BOLT

48

01643-31232

WASHER
