Запчасти Komatsu PC220LL-8 T-A LOG ПОГРУЗ. HEEL ЦИЛИНДР РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0L340

CYLINDER ASSEMBLY

1

707-13-14950

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL, DUST

4

721-58-10250

ROD

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL, DUST

7

707-27-14690

HEAD

8

176-63-56170

SEAL, DUST

9

07179-13114

RING, SNAP

10

707-52-90780

BUSHING

11

707-75-10160

RING, SNAP

12

707-51-10030

PACKING, ROD

13

707-51-10650

RING, BUFFER

14

707-35-91420

RING, BACK-UP

15

07000-15130

O-RING

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-14650

PISTON

19

01310-01216

SCREW

20

707-44-14150

RING, PISTON

21

707-39-14110

RING, WEAR

22

707-44-14910

RING

23

07001-05090

RING, BACK-UP

24

07000-15090

O-RING

25

707-86-68450

TUBE

26

07375-21045

BOLT

27

01643-51032

WASHER

28

07375-21060

BOLT

29

01643-51032

WASHER

30

07000-13030

O-RING

31

707-88-22680

BRACKET

32

707-88-21361

BAND

33

07375-21035

BOLT

34

01643-51032

WASHER

35

07283-32738

U-BOLT

36

01643-31032

WASHER

37

01597-01009

NUT

38

707-88-50080

BRACKET

39

707-88-33030

CAP

40

07371-30640

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$43

707-99-59020

KIT, SERVICE
