Запчасти Komatsu PC220LL-8 A9-AA РЫЧАГ КОРОМЫСЛА ДВИГАТЕЛЬ

1

6736-21-3210

BOLT (M8-1.25x50)

2

6732-61-6150

BOLT (M8-1.25x70)

3

6754-41-3110

ROD, PUSH

4

6754-41-5310

CROSSHEAD, VALVE

|$4

6754-41-5101

ASSEMBLY, ROCKER LEVER

|$5

NSS

LEVER, ROCKER

5

NSS

SOCKET, ROCKER LEVER

|$7

6754-41-5121

LEVER, ROCKER

6

6735-41-5550

NUT

7

NSS

LEVER, ROCKER (EXHAUST)

8

NSS

BALL, ROCKER LEVER

9

6754-41-5140

SCREW, ROCKER LEVER ADJUSTING

|$12

NSS

LEVER, ROCKER

10

NSS

SOCKET, ROCKER LEVER

|$14

6754-41-5221

LEVER, ROCKER

11

6735-41-5550

NUT

12

NSS

BALL, ROCKER LEVER

13

6754-41-5140

SCREW, ROCKER LEVER ADJUSTING

14

NSS

LEVER, ROCKER (INTAKE)

15

6754-41-5260

SUPPORT, ROCKER LEVER

16

6754-41-5180

SCREW

17

6754-41-5190

SHAFT, ROCKER LEVER

18

6754-11-7120

GASKET, ROCKER LEVER HOUSING

|$23

6754-12-7110

HOUSING, ROCKER LEVER

19

NSS

HOUSING, ROCKER LEVER

20

NSS

SLEEVE

21

6732-21-4180

SCREW

22

6754-81-9210

HARNESS, WIRING

23

6754-81-9230

CLIP, WIRE RETAINING

24

6754-81-9220

CLIP, WIRE RETAINING

25

6754-11-8150

STUD
