Запчасти Komatsu PC220LL-8 P-A МОТОР ХОДА МОТОР И ТОРМОЗ. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

1

NSS

SHAFT

2

NSS

BEARING

3

NSS

BEARING

4

NSS

SPACER KIT

|$5

NSS

SPACER, 1.6 MM

|$6

NSS

SPACER, 1.7 MM

|$7

NSS

SPACER, 1.8 MM

|$8

NSS

SPACER, 1.9 MM

|$9

NSS

SPACER, 2.0 MM

|$10

NSS

SPACER, 2.1 MM

|$11

NSS

SPACER, 2.2 MM

5

708-1F-12281

SEAL, OIL

6

708-8H-32160

SPACER

7

04065-07825

RING, SNAP

|$15

NSS

CYLINDER BLOCK ASSEMBLY

8

NSS

BLOCK, CYLINDER

9

NSS

PLATE, VALVE

10

NSS

PIN

11

NSS

PIN

12

NSS

SPACER

13

NSS

SPRING

14

NSS

RING, SNAP

15

NSS

RETAINER

16

NSS

RETAINER, SHOE

17

NSS

PISTON SUBASSEMBLY

18

NSS

CAM, ROCKER

19

NSS

BALL

20

708-8H-34190

PISTON

21

708-8H-34290

SPRING

22

708-8H-34151

SPRING

23

708-8K-14210

PLUG

24

07002-13334

O-RING

25

NSS

PLATE

26

NSS

DISC

27

NSS

PISTON, BRAKE

28

NSS

O-RING

29

NSS

RING, BACK-UP

30

NSS

O-RING

31

NSS

RING, BACK-UP

32

NSS

SPRING
