Запчасти Komatsu PC220LL-8 P-A МОТОР ХОДА МОТОР КОРПУС НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8H-00351

MOTOR ASSEMBLY

|$1

708-8H-14712

CASE SUBASSEMBLY

1

708-8H-31311

CASE, MOTOR

2

708-21-12541

PLUG

|$4

NSS

COVER SUBASSEMBLY, END

3

708-8H-31611

COVER, END

4

708-8H-36410

SPOOL

5

NSS

SPOOL

6

708-21-12541

PLUG

7

708-8H-34170

SPRING

8

NSS

PLUG

9

NSS

PIN, DOWEL

10

708-8H-11530

PLUG

11

07002-11423

O-RING

12

20B-27-11210

BLEEDER

13

706-73-72420

VALVE, TRAVEL MOTOR

14

706-73-72440

SPRING

15

708-8H-36150

PLUG

16

07000-12018

O-RING

17

07001-02018

RING, BACK-UP

18

706-78-71160

PISTON

19

708-8H-36121

SPRING

20

708-8H-16141

PLUG

21

07002-13634

O-RING

22

NSS

BALL

23

NSS

PLUG

24

NSS

O-RING

25

708-8E-16180

VALVE

26

NSS

PLUG

27

NSS

O-RING

28

NSS

O-RING

29

NSS

O-RING

30

NSS

PIN

31

NSS

BOLT

32

NSS

BOLT
