Запчасти Komatsu PC220LL-8 A-AA ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

|$0

6737-32-3121

ROD, ENGINE CONNECTING

1

NSS

ROD, ENGINE CONNECTING

2

6732-31-3320

BOLT, CONNECTING ROD CAP

3

6732-31-3132

BUSHING

4

6754-32-3410

BEARING, CONNECTING (UPPER)

5

6732-31-3420

BEARING, CONNECTING (LOWER)

|$6

6754-31-2110

KIT, ENGINE PISTON

6

NSS

PISTON

7

6754-31-2410

PIN, PISTON

8

6754-31-2010

SET, PISTON RING

|$10

NSS

RING, COMPRESSION PISTON (TOP)

|$11

NSS

RING, COMPRESSION PISTON (2ND)

|$12

NSS

RING, OIL PISTON

9

6732-31-2420

RING, RETAINING

10

6754-21-1191

NOZZLE, PISTON COOLING

11

6754-21-1180

SCREW, BANJO CONNECTOR

4

6754-32-3420

BEARING, CONNECTING ROD (0.25 MM OS)

4

6754-32-3430

BEARING, CONNECTING ROD (0.50 MM OS)

4

6754-32-3440

BEARING, CONNECTING ROD (0.75 MM OS)

4

6754-32-3450

BEARING, CONNECTING ROD (1.00 MM OS)

5

6738-39-3400

BEARING, CONNECTING ROD (0.25 MM OS)

5

6738-38-3400

BEARING, CONNECTING ROD (0.50 MM OS)

5

6738-37-3400

BEARING, CONNECTING ROD (0.75 MM OS)

5

6738-36-3400

BEARING, CONNECTING ROD (1.00 MM OS)

6

6754-31-2120

KIT, ENGINE PISTON .50 MM OVERSIZE

|$26

NSS

PISTON, ENGINE

7

6754-31-2410

PIN, PISTON

8

6754-39-2010

SET, PISTON RING .50 MM OVERSIZE

|$29

NSS

RING, COMPRESSION PISTON

|$30

NSS

RING, OIL PISTON

|$31

NSS

RING, COMPRESSION PISTON

9

6732-31-2420

RING, RETAINING
