Запчасти Komatsu PC220LL-8 K9-A КАБИНА РЫЧАГ УПРАВЛ-Я ХОДОМ OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

01010-81020

BOLT

2

01643-31032

WASHER

3

20Y-43-41121

COVER, TRAVEL CONTROL VALVE

4

01010-81020

BOLT

5

01643-31032

WASHER

6

20Y-43-41360

COLLAR

7

203-43-51620

SPRING

|$7

22U-43-21350

COVER ASSEMBLY, SPRING

8

NSS

COVER

9

22U-43-21360

SEAL

10

20Y-43-41111

LEVER

11

01010-D1045

BOLT

12

01643-71032

WASHER

13

01010-81030

BOLT

14

01643-31032

WASHER

15

22U-43-21111

PEDAL, L.H. - TRAVEL CONTROL

16

22U-43-21121

PEDAL, R.H. - TRAVEL CONTROL

17

22U-43-21131

LEVER, TRAVEL CONTROL

18

20Y-43-21231

KNOB, L.H.

19

20Y-43-21241

KNOB, R.H.

20

01023-20416

SCREW

21

20Y-62-18910

BOLT, EYE

22

07000-12018

O-RING

23

11Y-62-12160

ELBOW

24

02896-11008

O-RING

25

07002-11423

O-RING

26

20Y-62-18890

BOLT

27

07000-12015

O-RING

28

20Y-62-41390

ADAPTER

29

07002-11423

O-RING

30

20Y-06-21710

SWITCH, TRAVEL CONTROL VALVE

31

206-06-61130

SWITCH, TRAVEL CONTROL VALVE
