Запчасти Komatsu PC220LL-7L FIG. T-A ЦИЛИНДР КОВША РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0A380

CYLINDER, BUCKET ASSEMBLY

1

707-13-13480

CYLINDER, BUCKET

2

707-76-80470

BUSHING

3

07145-00080

SEAL, DUST

4

707-58-90940

ROD, PISTON

5

707-76-80480

BUSHING

6

20Y-70-23230

SEAL, DUST

7

707-27-13921

HEAD, CYLINDER

8

07179-13104

RING, SNAP

9

195-63-94170

SEAL, DUST

10

707-52-90680

BUSHING

11

707-51-90030

PACKING, ROD

12

07000-15120

O-RING

13

707-35-91320

RING, BACK-UP

14

707-51-90640

RING, BUFFER

15

01010-81670

BOLT

16

01643-51645

WASHER

17

707-36-13780

PISTON

18

707-44-13180

RING, PISTON

19

707-39-13150

RING, WEAR

20

707-44-13911

RING

21

707-35-90940

RING

22

07000-15080

O-RING

23

01310-01216

SCREW

24

07020-00000

FITTING, GREASE

25

07020-00900

FITTING, GREASE

26

707-86-66350

TUBE

27

01435-01055

BOLT

28

01435-01040

BOLT

29

07000-13030

O-RING

30

707-88-22640

BRACKET

31

707-88-21331

BAND

32

01435-01030

BOLT

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER

|$36

707-99-47570

SERVICE KIT
