Запчасти Komatsu PC220LL-7L FIG. T-A ЦИЛИНДР РУКОЯТИ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0A371

CYLINDER ASSEMBLY

1

707-13-14550

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL, DUST

4

707-58-10681

ROD, PISTON

5

707-27-14930

HEAD, CYLINDER

6

07179-13114

RING, SNAP

7

176-63-56170

SEAL, DUST

8

707-52-90780

BUSHING

9

707-51-10030

PACKING, ROD

10

07000-15130

O-RING

11

707-35-91420

RING, BACK-UP

12

707-51-10640

RING, BUFFER

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-14650

PISTON

16

707-44-14180

RING, PISTON

17

707-39-14110

RING, WEAR

18

707-44-14910

RING

19

707-71-61080

PLUNGER

20

07000-15090

O-RING

21

07001-05090

RING, BACK-UP

22

01310-21216

SCREW

23

707-71-70270

PLUNGER

24

07020-00000

FITTING, GREASE

25

707-71-32780

COLLAR

26

707-35-91420

RING, BACK-UP

27

07000-15130

O-RING

28

04260-00635

BALL

29

707-71-91270

CAP

30

707-83-13010

VALVE

31

07750-01628

SPRING

32

707-87-14070

PLUG

33

07002-12034

O-RING

34

707-86-66340

TUBE

35

20D-62-17860

ELBOW

36

01435-01055

BOLT

37

01435-01040

BOLT

38

07000-13030

O-RING

39

01435-01075

BOLT

40

07000-13035

O-RING

41

707-88-22630

BRACKET

42

707-88-21321

BAND

43

01435-01030

BOLT

44

707-88-11560

PLATE

45

07283-22738

CLIP

46

01599-01011

NUT

47

01643-31032

WASHER

|$49

707-99-58070

SERVICE KIT
