Запчасти Komatsu PC220LL-7L FIG. P-A МОТОР ХОДА - МОТОР КОРПУС НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8H-00330

MOTOR ASSEMBLY

|$1

708-8H-04710

CASE SUB ASSEMBLY

1

NSS

CASE, MOTOR

2

NSS

PLUG

|$4

708-8H-04720

END COVER SUB ASSEMBLY

3

NSS

COVER, END

4

NSS

SPOOL

5

NSS

SPOOL

6

NSS

PLUG

7

NSS

SPRING

8

NSS

PLUG

9

706-75-42820

PIN, DOWEL

10

708-8H-11530

PLUG

11

07002-11423

O-RING

12

20B-27-11210

BLEEDER

13

706-73-72420

VALVE

14

706-73-72440

SPRING

15

708-8H-36150

PLUG

16

07000-12018

O-RING

17

07001-02018

RING, BACK-UP

18

706-78-71160

PISTON

19

708-8H-36121

SPRING

20

708-8H-16141

PLUG

21

07002-13634

O-RING

22

04260-00793

BALL

23

706-8E-14110

PLUG

24

07002-11023

O-RING

25

708-8E-16180

VALVE

26

708-8E-16160

PLUG

27

07002-11023

O-RING

28

708-8H-31210

O-RING

29

07000-12012

O-RING

30

04020-01228

PIN

31

01252-62055

BOLT

32

01252-62095

BOLT
