Запчасти Komatsu PC220LL-7L FIG. K-A ОСНОВН. КОНСТРУКЦИЯ - КОНДИЦ. ВОЗДУХА И НИЖН. КРЫШКА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-979-6111

UNIT ASSEMBLY, AIR CONDITIONER

2

01010-81020

BOLT

3

01643-31032

WASHER

4

20Y-979-6241

DUCT ASSEMBLY

5

20Y-979-6341

SENSOR

6

20Y-979-6351

CLAMP

7

01435-00612

BOLT

8

01252-70516

BOLT

9

01640-20508

WASHER

10

20Y-979-6231

DUCT

11

01435-40612

BOLT

12

20Y-979-6261

FILTER

13

20Y-54-65130

GROMMET

14

20Y-54-65180

GROMMET

15

20Y-54-65190

COVER

16

01010-D1016

BOLT

17

01643-71032

WASHER

18

20Y-979-6481

COVER

19

20Y-54-65790

BOLT

20

01643-70623

WASHER

21

20Y-54-65690

WASHER

22

20Y-979-6591

COVER

23

22U-43-21340

SHEET

24

01010-80820

BOLT

25

01643-30823

WASHER

26

102-60-15240

SEAT

27

01245-00820

SCREW

28

01643-70823

WASHER

1

20Y-979-6111

UNIT ASSEMBLY, AIR CONDITIONER

2

01010-81020

BOLT

3

01643-31032

WASHER

4

20Y-979-6241

DUCT ASSEMBLY

5

20Y-979-6341

SENSOR

6

20Y-979-6351

CLAMP

7

01435-00612

BOLT

8

01252-70516

BOLT

9

01640-20508

WASHER

10

20Y-979-6231

DUCT

11

01435-40612

BOLT

12

20Y-979-6261

FILTER

13

20Y-54-65130

GROMMET

14

20Y-54-65180

GROMMET

15

20Y-54-65190

COVER

16

01010-D1016

BOLT

17

01643-71032

WASHER

18

20Y-979-6481

COVER

19

20Y-54-65790

BOLT

20

01643-70623

WASHER

21

20Y-54-65690

WASHER

22

20Y-979-6591

COVER

23

22U-43-21340

SHEET

24

01010-80820

BOLT

25

01643-30823

WASHER

26

102-60-15240

SEAT

27

01245-00820

SCREW

28

01643-70823

WASHER
