Запчасти Komatsu PC220LL-6 FIG. P-A МОТОР ХОДА - КОРПУС SUB ASSEMBLY НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8F-00120

TRAVEL MOTOR ASSEMBLY

|$1

708-8F-04640

CASE SUB ASSEMBLY

1

NSS

CASE, MOTOR

2

NSS

PLUG

|$4

708-8F-04621

END COVER SUB ASSEMBLY

3

NSS

COVER, END

4

NSS

SPOOL

5

NSS

PLUG

6

NSS

PLUG

7

NSS

SPOOL

8

708-8F-34170

SPRING

9

708-8H-34210

SEAT

10

708-8H-34180

RING

11

708-8H-11530

PLUG

12

07002-11423

O-RING

13

20B-27-11210

BLEEDER

14

708-8F-36611

SPRING

15

NSS

RING

16

708-8H-36121

SPRING

17

708-8F-36311

COVER

18

07000-13040

O-RING

19

700-93-11320

O-RING

20

07000-11009

O-RING

21

01252-61235

BOLT

22

708-8F-34120

VALVE

23

722-10-91130

SPRING

24

708-8F-34110

PLUG

25

07002-11823

O-RING

26

708-8E-16180

VALVE

27

708-8E-16160

PLUG

28

07002-11023

O-RING

29

708-8F-31610

O-RING

30

07000-11009

O-RING

31

04020-01228

PIN

32

708-8F-31210

BOLT
