Запчасти Komatsu PC220LL-6 FIG. N-A МОТОР ПОВОРОТА - COMPLETE ASSEMBLY ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$0

706-75-01150

SWING MOTOR ASSEMBLY

1

565-14-22440

O-RING

2

01252-61445

BOLT

3

706-75-43660

SHAFT, DRIVE

4

706-75-42880

BEARING

5

706-75-43810

SPACER

6

706-7E-11260

SPRING

7

706-7E-11270

SEAT

8

706-76-40890

BEARING

9

706-75-05040

SPACER KIT

|$10

NSS

SPACER, 3.1 MM

|$11

NSS

SPACER, 3.4 MM

|$12

NSS

SPACER, 3.7 MM

10

04064-04518

RING, SNAP

11

706-7E-11280

SEAL, OIL

12

706-75-43720

SPACER

13

07064-06220

RING

14

706-75-43190

BLOCK, CYLINDER

15

706-75-43741

PLATE, VALVE

16

706-75-43750

PIN, DOWEL

17

706-75-43120

SHAFT, CENTER

18

706-75-43130

RING, CENTER

19

706-75-41110

SPRING

|$23

706-75-05020

RETAINER KIT

20

NSS

RETAINER

21

NSS

SCREW

22

706-75-43160

PISTON SUB ASSEMBLY

23

706-75-92130

PLATE

24

706-75-92340

PLATE

25

706-75-92350

DISK

26

706-75-92380

PISTON, BRAKE

27

706-75-92390

RING, BRAKE

28

07000-12145

O-RING

29

706-75-92310

O-RING

30

706-75-92170

SPRING
