Запчасти Komatsu PC220LL-6 FIG. A-AA КОЛЕНВАЛ ДВИГАТЕЛЬ

|$0

6736-31-1100

CRANKSHAFT ASSEMBLY

1

6732-31-1211

GEAR, CRANKSHAFT

2

NSS

CRANKSHAFT

3

6732-21-6150

PIN, DOWEL

|$4

6735-21-8100

SET, MAIN BEARING - STANDARD

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$8

6736-29-8100

SET, MAIN BEARING - 0.25MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$12

6736-28-8100

SET, MAIN BEARING - 0.50MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$16

6736-27-8100

SET, MAIN BEARING - 0.75MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$20

6736-26-8100

SET, MAIN BEARING - 1.00MM OVER

4

NSS

BEARING, MAIN UPPER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$24

6731-21-8610

SET, CRANKSHAFT THRUST BRG - 0.50MM OVER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

|$27

6731-21-8620

SET, CRANKSHAFT THRUST BRG - 1.00MM OVER

5

NSS

BEARING, THRUST

6

NSS

BEARING, LOWER

7

6736-39-1221

KIT, FRONT CRANK SLEEVE

8

6736-39-1140

KIT, REAR CRANK SLEEVE
