Запчасти Komatsu PC220LL-6 FIG. A-AA БЛОК ЦИЛИНДРОВ - С ENСЕРДЦЕВИНА БЛОК ДВИГАТЕЛЬ

|$0

6735-21-1140

CYLINDER BLOCK ASSEMBLY

1

NSS

BLOCK, CYLINDER

2

6732-21-1411

BUSHING

3

6732-21-1611

BOLT (M12-1.50x119)

4

6731-21-1260

CAP, MAIN BEARING

5

6736-21-1810

PLUG, EXPANSION

6

6736-21-1820

PLUG, EXPANSION

7

6732-21-1810

PLUG, EXPANSION

8

6732-21-1910

DOWEL, RING

|$9

6731-21-1210

KIT, BLOCK HARDWARE

9

6732-21-6140

DOWEL, RING

10

6731-21-1190

NOZZLE, PISTON COOLING

11

6732-21-6130

PLUG, EXPANSION

12

6732-21-6120

DOWEL, PIN

13

6732-11-1910

PLUG, PIPE

14

6732-21-1960

PLUG, THREADED (M10-1.00)

15

6735-21-5530

PLUG, EXPANSION

16

6732-21-1910

DOWEL, RING

17

6732-21-5530

PLUG, EXPANSION

18

6732-21-6160

PLUG, EXPANSION

19

6732-11-1920

PLUG, PIPE

20

6735-21-1910

PLUG, THREADED

21

6735-21-1940

PLATE, COVER

22

6732-21-3120

BOLT (M8-1.25x16)

2

6736-29-1410

BUSHING, OVERSIZE (NO. 1 BORE)

2

6736-29-1420

BUSHING, OVERSIZE (NO. 2-5 BORE)

4

6731-21-1260

CAP, BEARING MAIN

23

6736-29-2110

SLEEVE, SALVAGE
