Запчасти Komatsu PC220LC-8 T-A ЦИЛИНДР СТРЕЛЫПРАВ. РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0H850

CYLINDER ASSEMBLY, RIGHT SIDE

1

707-13-13920

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL, DUST

4

707-58-95280

ROD, PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL, DUST

7

707-27-13850

CYLINDER HEAD

8

07179-13109

RING, SNAP

9

NSS

SEAL, DUST

10

707-52-90721

BUSHING

11

707-75-95030

RING, SNAP

12

707-51-95030

PACKING

13

07000-15125

O-RING

14

707-35-91370

RING, BACK-UP

15

707-51-95650

RING

16

01010-61875

BOLT

17

707-41-11840

WASHER

18

707-36-13771

PISTON

19

707-44-13250

RING, PISTON

20

707-39-13530

RING, WEAR

21

707-44-13920

RING

22

707-71-71010

PLUNGER

23

07000-15085

O-RING

24

707-35-90960

RING, BACK-UP

25

01310-21216

SCREW

26

707-71-35010

COLLAR

27

707-35-91370

RING, BACK-UP

28

07000-15125

O-RING

29

707-86-67850

TUBE

30

707-86-66330

TUBE

31

07372-21060

BOLT

32

01643-51032

WASHER

33

07372-21045

BOLT

34

01643-51032

WASHER

35

07000-13030

O-RING

36

707-88-28160

BRACKET

37

707-88-21261

BAND

38

07372-21035

BOLT

39

01643-51032

WASHER

40

07283-32738

CLIP, PIPE

41

01597-01009

NUT

42

01643-31032

WASHER

43

707-88-33030

CAP

44

07371-30640

FLANGE, SPLIT

45

07372-21035

BOLT

46

01643-51032

WASHER

|$47

707-99-50680

SERVICE KIT, BOOM CYLINDER
