Запчасти Komatsu PC220LC-8 P-A МОТОР ХОДА МОТОР И КОНЕЧНАЯ ПЕРЕДАЧА (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

150-27-00410

SEAL ASSEMBLY

1

NSS

SEAL

2

14S-27-11270

O-RING

3

22U-27-21182

HUB

4

20Y-27-22230

BEARING

5

22U-27-21220

O-RING

6

20Y-27-22261

LOCK

7

20Y-27-22270

LOCK

8

01010-81020

BOLT

9

22U-27-21171

CARRIER

10

22U-27-21140

GEAR

11

20Y-27-22220

BEARING

12

20Y-27-21250

WASHER

13

22U-27-21230

PIN

14

20Y-27-21290

PIN

15

20Y-27-13310

WASHER

16

22U-27-21130

GEAR

17

22U-27-21210

WASHER, THRUST

18

22U-27-21153

GEAR

19

22U-27-21161

CARRIER

20

22U-27-21120

GEAR

21

20Y-27-22210

BEARING

22

22U-27-21240

WASHER, THRUST

23

20Y-27-21220

PIN

24

20Y-27-21280

PIN

25

22U-27-21110

SHAFT

26

20Y-27-21310

WASHER, THRUST

27

22U-27-21192

COVER

28

20Y-27-22250

BUTTON

29

20Y-27-13281

BOLT

30

01643-31645

WASHER

31

07049-01012

PLUG

32

07044-12412

PLUG, WITH MAGNET

33

07002-02434

O-RING

34

20Y-27-77110

SPROCKET

35

20Y-27-11561

BOLT

36

01010-61660

BOLT

37

01643-31645

WASHER

38

20Y-30-21192

COVER

39

01010-81230

BOLT

40

01643-31232

WASHER
