Запчасти Komatsu PC220LC-8 P-A МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА (/) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

206-27-00423

FINAL DRIVE ASSEMBLY

|$1

708-8F-00192

MOTOR ASSEMBLY

|$2

708-8F-04660

CASE SUBASSEMBLY

1

NSS

CASE, MOTOR

2

NSS

PLUG

|$5

708-8F-04192

COVER SUBASSEMBLY, END

3

NSS

COVER, END

4

NSS

SPOOL

5

NSS

PLUG

6

NSS

PLUG

7

NSS

SPOOL

8

708-8F-34220

SPRING

9

708-8H-11530

PLUG

10

07002-11423

O-RING

11

20B-27-11210

BLEEDER

|$15

702-73-02112

VALVE ASSEMBLY, RELIEF

12

NSS

SLEEVE

13

NSS

VALVE

14

NSS

SPRING

15

NSS

SEAL

16

NSS

SCREW

17

NSS

NUT

18

708-8F-36611

SPRING

19

NSS

RING

20

708-8H-36121

SPRING

21

708-8F-36311

COVER

22

07000-13040

O-RING

23

700-93-11320

O-RING

24

07000-11009

O-RING

25

01252-61235

BOLT, HEXAGON SOCKET HEAD

26

708-8F-34120

VALVE

27

722-10-91130

SPRING

28

708-8F-34110

PLUG

29

07002-11823

O-RING

30

708-8E-16180

VALVE

31

708-8F-31660

PLUG

32

07000-11006

O-RING

33

07001-01006

RING, BACK-UP

34

07002-11223

O-RING

35

708-8F-31610

O-RING

36

07000-11009

O-RING

37

04020-01228

PIN

38

708-8F-31210

BOLT
