Запчасти Komatsu PC220LC-8 A9-AA7 МАСЛ. ФИЛЬТР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC220LC-8 - A9-AA7 МАСЛ. ФИЛЬТР ДВИГАТЕЛЬ
6
7
4
2
10
3
5
12
1
9
8
11
6
7
4
2
10
3
5
12
1
9
8
11

Артикул

Название

Примечание

Количество

|$0

6754-52-5310

HEAD, LUBRICATING OIL FILTER

1

NSS

HEAD, LUBRICATING OIL FILTER

2

6206-61-5170

PLUG, PIPE

3

07043-A0108

PLUG, PIPE

4

6731-51-5260

CONNECTOR, MALE

5

6738-51-5260

CONNECTOR, MALE

6

6754-51-9810

HOSE, FLEXIBLE

7

6754-51-9910

HOSE, FLEXIBLE

8

6736-51-5142

FILTER, LUBRICATING OIL

9

6732-71-3220

BOLT (M8-1.25x20)

10

6734-21-8610

BOLT (M10-1.50x95)

11

6738-51-9950

BRACE, FILTER

12

6211-11-9790

SPACER, MOUNTING

|$0

6754-52-5310

HEAD, LUBRICATING OIL FILTER

1

NSS

HEAD, LUBRICATING OIL FILTER

2

6206-61-5170

PLUG, PIPE

3

07043-A0108

PLUG, PIPE

4

6731-51-5260

CONNECTOR, MALE

5

6738-51-5260

CONNECTOR, MALE

6

6754-51-9810

HOSE, FLEXIBLE

7

6754-51-9910

HOSE, FLEXIBLE

8

6736-51-5142

FILTER, LUBRICATING OIL

9

6732-71-3220

BOLT (M8-1.25x20)

10

6734-21-8610

BOLT (M10-1.50x95)

11

6738-51-9950

BRACE, FILTER

12

6211-11-9790

SPACER, MOUNTING

Выбрано товаров: 26
