Запчасти Komatsu PC220LC-8 H-A ОСНОВН. НАСОС PRESSURE СЕНСОР. ГЛАВН. КЛАПАН ГИДРАВЛИКА

1

702-21-57400

VALVE, PILOT

N/I

702-21-57410

SOLENOID

N/I

700-80-61260

O-RING

N/I

NSS

BODY

N/I

NSS

SPOOL

N/I

NSS

SPRING

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

702-21-54930

FILTER

N/I

723-11-19960

O-RING

N/I

702-21-54180

BOLT

N/I

702-21-54910

O-RING

N/I

NSS

PLUG

2

01252-60635

BOLT, HEXAGON SOCKET HEAD

3

20Y-62-22790

BAND, RED

4

702-21-57400

VALVE, PILOT

N/I

702-21-57410

SOLENOID

N/I

700-80-61260

O-RING

N/I

NSS

BODY

N/I

NSS

SPOOL

N/I

NSS

SPRING

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

702-21-54930

FILTER

N/I

723-11-19960

O-RING

N/I

702-21-54180

BOLT

N/I

702-21-54910

O-RING

N/I

NSS

PLUG

5

01252-60635

BOLT, HEXAGON SOCKET HEAD

6

20Y-62-22830

BAND, WHITE

7

702-21-57400

VALVE, PILOT

N/I

702-21-57410

SOLENOID

N/I

700-80-61260

O-RING

N/I

NSS

BODY

N/I

NSS

SPOOL

N/I

NSS

SPRING

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

NSS

SHIM

N/I

702-21-54930

FILTER

N/I

723-11-19960

O-RING

N/I

702-21-54180

BOLT

N/I

702-21-54910

O-RING

N/I

NSS

PLUG

8

01252-60635

BOLT, HEXAGON SOCKET HEAD

9

20Y-62-22810

BAND, YELLOW

10

708-2L-35941

PLUG

11

07000-B1008

O-RING

12

07001-01008

RING, BACK-UP

13

07002-61423

O-RING
