Запчасти Komatsu PC220LC-8 H-7A ОСНОВН. НАСОС ЗАДН. CRADLE ГИДРАВЛИКА

1

708-2L-32170

SHAFT, REAR

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|$5

NSS

WASHER, T= 3.1 MM

|$6

NSS

WASHER, T= 3.0 MM

|$7

NSS

WASHER, T= 2.9 MM

|$8

NSS

WASHER, T= 2.8 MM

4

708-25-12790

RING, SNAP

|$10

708-2L-06480

BLOCK ASSEMBLY, REAR

5

708-2L-33190

BLOCK, CYLINDER

6

708-2L-33180

PLATE, VALVE

7

720-68-19610

PIN

8

04065-04818

RING, SNAP

9

708-2L-23131

SEAT

10

708-2L-33160

SPRING

11

708-7L-13140

SEAT

12

708-2L-23351

GUIDE, RETAINER

13

708-2L-23360

PIN

14

708-2L-33350

RETAINER, SHOE

15

708-2L-33430

PISTON SUBASSEMBLY

|$22

NSS

CRADLE ASSEMBLY

16

NSS

CRADLE

17

NSS

CAM, ROCKER

18

04020-01228

PIN

19

207-62-K3180

BOLT, HEXAGON SOCKET HEAD
