Запчасти Komatsu PC220LC-8 ЦИЛИНДР РУКОЯТИ(№8-) ЦИЛИНДР РУКОЯТИ, ЧАС. СМАЗКА INTERVAL, СТРЕЛА И РУКОЯТЬ ANTI-DROP КЛАПАН

|$0

707-01-0J840

Cylinder Assembly

1

707-13-14820

Cylinder

2

721-58-10070

Rod, Piston

3

707-76-80010

Bushing

4

07145-00080

Seal, Dust, (Kit : K08)

5

707-76-80010

Bushing

6

07145-00080

Seal, Dust, (Kit : K08)

7

07020-00000

Fitting, Grease

8

707-71-34990

Collar

9

707-35-91420

Ring, Back-up, (Kit : K08)

10

07000-15130

O-ring, (Kit : K08)

11

707-71-71020

Plunger

12

707-71-80270

Plunger

13

04260-00635

Ball, Steel

14

707-71-91270

Cap

15

707-27-14690

Head, Cylinder

16

707-56-10740

Seal, Dust, (Kit : K08)

17

07179-13114

Ring, Snap

18

707-51-10030

Packing, Rod, (Kit : K08)

19

707-51-10650

Ring, Buffer, (Kit : K08)

20

707-52-90781

Bushing

21

07000-15130

O-ring, (Kit : K08)

22

707-35-91420

Ring, Back-up, (Kit : K08)

23

01010-81875

Bolt

24

707-41-11840

Washer

25

707-75-10160

Ring, Snap

26

707-36-14650

Piston

27

707-44-14150

Ring, Piston, (Kit : K08)

28

707-39-14110

Ring, Wear, (Kit : K08)

29

707-44-14910

Ring

30

07000-15090

O-ring, (Kit : K08)

31

07001-05090

Ring, Back-up, (Kit : K08)

32

01310-01216

Screw

33

707-83-13010

Valve

34

07750-01628

Spring

35

707-87-14070

Plug

36

07002-12034

O-ring, (Kit : K08)
