Запчасти Komatsu PC220LC-8 ЦИЛИНДР СТРЕЛЫ, ПРАВ. (№877-) ЦИЛИНДР СТРЕЛЫ, БОЛЬШ. DIAMETER ТИП

|$0

707-01-0H850

Cylinder Assembly

|$1

707-01-XH860

Cylinder Group

1

707-13-13920

Cylinder

2

707-58-95280

Rod, Piston

3

707-76-80431

Bushing

4

07145-00080

Seal, Dust, (Kit : K06)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K06)

7

707-71-35010

Collar

8

707-35-91370

Ring, Back-up, (Kit : K06)

9

07000-15125

O-ring, (Kit : K06)

10

707-71-71010

Plunger

11

707-27-13850

Head, Cylinder

12

707-56-95740

Seal, Dust, (Kit : K06)

13

07179-13109

Ring, Snap

14

707-52-90721

Bushing

15

707-51-95030

Packing, Rod, (Kit : K06)

16

707-51-95650

Ring, Buffer, (Kit : K06)

17

707-35-91370

Ring, Back-up, (Kit : K06)

18

07000-15125

O-ring, (Kit : K06)

19

01010-81875

Bolt

20

707-41-11840

Washer

21

707-75-95030

Ring, Snap

22

707-36-13771

Piston

23

707-44-13250

Ring, Piston, (Kit : K06)

24

707-39-13530

Ring, Wear, (Kit : K06)

25

707-44-13920

Ring

26

01310-01216

Screw

27

07000-15085

O-ring, (Kit : K06)

28

707-35-90960

Ring, Back-up, (Kit : K06)

29

707-86-67850

Tube,R.H.

30

707-86-66330

Tube,R.H.

31

707-88-28160

Bracket,R.H.

32

07372-21060

Bolt

33

01643-51032

Washer

34

07372-21045

Bolt

35

01643-51032

Washer

36

707-88-21261

Band

37

07000-13030

O-ring, (Kit : K06)

38

07372-21035

Bolt

39

01643-51032

Washer

40

07283-32738

Clip, Pipe

41

01597-01009

Nut

42

01643-31032

Washer

43

07371-30640

Flange, Split

44

707-88-33030

Cap
