Запчасти Komatsu PC220LC-8 РУКОЯТЬ, УСИЛ.ENED, ДЛЯ MACHINE С -ДОПОЛН. АКТУАТОР (/) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

707-01-XS880

Cylinder Group

|1

707-01-0H920

Cylinder Assembly

1

707-13-13880

Cylinder

2

707-76-80431

Bushing

3

707-77-80010

Seal, Dust

4

707-58-90E60

Rod, Piston

5

707-76-80020

Bushing

6

20Y-70-23230

Seal, Dust

7

707-27-13750

Cylinder Head

8

07179-13104

Ring, Snap

9

707-56-90730

Seal, Dust

10

707-52-90680

Bushing

11

707-75-90110

Ring, Snap

12

707-51-90030

Packing

13

07000-15120

O-ring

14

707-35-91320

Ring, Back-up

15

707-51-90650

Ring

16

01010-81875

Bolt

17

01643-51645

Washer

18

707-36-13780

Piston

19

707-44-13150

Ring, Piston

20

707-39-13150

Ring, Wear

21

707-44-13911

Ring

22

707-35-90940

Ring, Back-up

23

07000-15080

O-ring

24

01310-01216

Screw

25

07020-00000

Fitting, Grease

26

07020-00000

Fitting, Grease

27

707-86-67820

Tube

28

07372-21060

Bolt

29

01643-51032

Washer

30

07372-21045

Bolt

31

01643-51032

Washer

32

07000-13030

O-ring

33

707-88-22640

Bracket

34

707-88-21331

Band

35

07372-21035

Bolt

36

01643-51032

Washer

37

07283-32738

Clip, Pipe

38

01597-01009

Nut

39

01643-31032

Washer

40

707-88-33030

Cap

41

07371-30640

Flange, Split

42

07372-21035

Bolt

43

01643-51032

Washer
