Запчасти Komatsu PC220LC-8 КАБИНА (9/) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

22U-54-25660

Seal

2

20Y-43-41760

Seat

3

01010-81025

Bolt

4

01643-31032

Washer

5

01643-31032

Washer

6

20Y-62-25360

Bracket

7

01010-D1035

Bolt

8

01643-71032

Washer, Flat

9

207-43-81250

Pedal, For Machine With 1-additional Actuator Circuit

10

01010-D1045

Bolt

11

01643-71032

Washer, Flat

12

22U-54-25541

Plate

13

01010-81025

Bolt

14

01643-31032

Washer

15

207-43-81220

Pedal, For Machine With 1-additional Actuator Circuit

16

01240-00816

Screw, Hexagon Socket Head

17

207-43-81240

Cap

18

20T-910-8660

Nipple

19

07000-12011

O-ring

20

20Y-62-52160

Elbow

21

02896-11008

O-ring

22

07000-12011

O-ring

23

20Y-62-43470

Nipple

24

02896-11008

O-ring

25

11Y-62-12140

Nipple

26

02896-11008

O-ring

27

07000-12011

O-ring

28

20Y-62-52330

Hose, L=900mm

29

20Y-62-52340

Hose, L=4100mm

30

20Y-62-52350

Hose, L=3350mm

31

208-62-72480

Hose, L=1080mm

32

20Y-62-22790

Band, Red

33

20Y-62-22810

Band, Yellow

34

20Y-62-22820

Band, Blue

35

08034-20519

Band

36

08034-20823

Band

37

04435-51210

Clip

38

01583-11408

Nut

39

206-06-61130

Switch

40

08193-21012

Clip

41

08053-01510

Clip

42

01580-01008

Nut

43

08034-20536

Band
