Запчасти Komatsu PC220LC-8 ЦИЛИНДР СТРЕЛЫ( ЧАС. СИСТЕМА СМАЗКИ) (БОЛЬШ. DIAMETER ТИП ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS810

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XS820

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0H850

CYLINDER ASS'Y

1

707-13-13920

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95280

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-13850

HEAD,CYLINDER

8

07179-13109

RING,SNAP

9

707-56-95510

SEAL,DUST (KIT)

10

707-52-90720

BUSHING

11

707-75-95030

RING,SNAP

12

707-51-95030

PACKING,ROD (KIT)

13

07000-15125

O-RING (KIT)

14

707-35-91370

RING,BACK-UP (KIT)

15

707-51-95650

RING,BUFFER (KIT)

16

01010-81875

BOLT

17

707-41-11840

WASHER

18

707-36-13771

PISTON

19

707-44-13250

RING,PISTON (KIT)

20

707-39-13530

RING,WEAR (KIT)

21

707-44-13920

RING

22

707-71-71010

PLUNGER

23

07000-15085

O-RING (KIT)

24

707-35-90960

RING,BACK-UP (KIT)

25

01310-01216

SCREW

26

707-71-35010

COLLAR

27

707-35-91370

RING,BACK-UP (KIT)

28

07000-15125

O-RING (KIT)

29

707-86-67840

TUBE,L.H.

29

707-86-67850

TUBE,R.H.

30

707-86-66310

TUBE,L.H.

30

707-86-66330

TUBE,R.H.

31

07372-51060

BOLT

32

01643-51032

WASHER

33

07372-51045

BOLT

34

01643-51032

WASHER

35

07000-13030

O-RING (KIT)

36

707-88-28150

BRACKET,L.H.

36

707-88-28160

BRACKET,R.H.

37

707-88-21261

BAND

38

07372-21035

BOLT

39

01643-51032

WASHER

40

07283-32738

CLIP

41

01597-01009

NUT

42

01643-31032

WASHER

43

707-88-33030

CAP

44

07371-30640

FLANGE,SPLIT

45

07372-21035

BOLT

46

01643-51032

WASHER

|$56

707-99-50680

SERVICE KIT
