Запчасти Komatsu PC220LC-8 МЕХАНИЗМ ПОВОРОТА (МОТОР И MACHINERY) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7G-01170

MOTOR ASS'Y

1

706-7G-01041

MOTOR ASS'Y

1

706-7G-03090

MOTOR SUB ASS'Y

2

22U-26-21280

RING

3

07042-00312

PLUG

4

206-26-73310

CASE

5

206-26-73150

BEARING

6

206-26-73160

BEARING

7

206-26-73130

SHAFT

8

206-26-73140

SPACER

9

07000-15100

O-RING

10

20Y-26-22420

SEAL

11

206-26-73120

COVER

12

01010-81040

BOLT

13

01643-31032

WASHER

14

07000-15310

O-RING

15

206-26-71480

CARRIER

16

206-26-71440

GEAR

17

22U-26-21320

BEARING

18

206-26-71520

THRUST WASHER

19

206-26-71510

PIN

20

20Y-26-21330

PIN

21

20Y-26-21240

PLATE

22

112-32-11211

BOLT

23

206-26-71452

GEAR

24

20K-22-11190

O-RING

25

01010-81440

BOLT

26

01643-31445

WASHER

27

206-26-71430

GEAR

28

04260-01270

BALL

29

206-26-71471

CARRIER

30

206-26-71420

GEAR

31

20Y-27-22210

BEARING

32

22U-26-21230

WASHER

33

206-26-71210

PIN

34

04064-03515

RING

35

206-26-71350

HOLDER

36

206-26-71410

GEAR

37

206-26-71341

PLATE
