Запчасти Komatsu PC220LC-8 БОКОВ. КРЫШКА¤ ЛЕВ. ЧАСТИ КОРПУСА

1

20Y-54-71312

FRAME

2

20Y-54-71322

FRAME

3

20Y-54-71331

FRAME

4

20Y-54-71341

FRAME

5

01010-81225

BOLT

6

01643-31232

WASHER

7

206-54-21281

COVER

7

206-54-21280

COVER

8

20Y-54-63414

HINGE (WELDED)

9

198-54-41982

LOCK ASS'Y (WELDED)

10

20Y-54-72870

SHEET

11

01010-81225

BOLT

12

01643-31232

WASHER

13

206-54-21261

COVER

13

206-54-21260

COVER

14

20Y-54-63390

SHEET

15

20Y-54-63414

HINGE (WELDED)

16

20Y-54-73841

SHEET

16

20Y-54-73840

SHEET

17

20Y-54-73752

SHEET

17

20Y-54-73751

SHEET

18

01010-81225

BOLT

19

01643-31232

WASHER

20

20Y-54-61470

PLATE

21

01010-81225

BOLT

22

01643-31232

WASHER

23

205-54-53550

DOVE TAIL

24

01010-80612

BOLT

25

01643-30623

WASHER

26

20Y-54-28170

BRACKET

27

01010-81225

BOLT

28

01643-31232

WASHER

29

205-54-51970

DOVE TAIL

30

01010-80616

BOLT

31

01643-30623

WASHER

32

20Y-54-61372

BRACKET

33

01010-81225

BOLT

34

01643-31232

WASHER

35

20Y-54-11611

STOPPER

36

01580-11008

NUT

37

20Y-54-29232

BAR

38

20Y-54-71361

SHEET

39

20Y-54-72670

SHEET

40

20Y-54-72750

SHEET

41

20Y-54-72740

SHEET

42

20Y-54-71222

FRAME

|$70

20Y-54-71282

FRAME

43

FRAME

44

20Y-54-71241

SHEET

45

01010-81230

BOLT

46

01643-31232

WASHER

47

20Y-54-12550

COLLAR

48

01010-81225

BOLT

49

01643-31232

WASHER

50

01010-81230

BOLT

51

01643-31232

WASHER

52

01010-81230

BOLT

53

01643-31232

WASHER
