Запчасти Komatsu PC220LC-7L ЦИЛИНДР СТРЕЛЫ(БОЛЬШ. DIAMETER ТИП) РАБОЧЕЕ ОБОРУДОВАНИЕ

G-1

707-01-XY500

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XY510

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0C040

CYLINDER ASS'Y

1

707-13-13580

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-95170

ROD,PISTON

5

707-76-80431

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-13961

HEAD,CYLINDER

8

07179-13109

RING,SNAP

9

707-56-95510

SEAL,DUST (KIT)

10

707-52-90720

BUSHING

11

707-51-95030

PACKING,ROD (KIT)

12

07000-15125

O-RING (KIT)

13

707-35-91370

RING,BACK-UP (KIT)

14

707-51-95640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-13771

PISTON

18

707-44-13280

RING,PISTON (KIT)

19

707-39-13530

RING,WEAR (KIT)

20

707-44-13920

RING

21

707-71-61070

PLUNGER

22

07000-15085

O-RING (KIT)

23

707-35-90960

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-32860

COLLAR

26

707-35-91370

RING,BACK-UP (KIT)

27

07000-15125

O-RING (KIT)

28

707-86-66420

TUBE,L.H.

|$36

707-86-66430

TUBE,R.H.

29

707-86-66310

TUBE,L.H.

|$38

707-86-66330

TUBE,R.H.

30

01435-01055

BOLT

31

01435-01040

BOLT

32

07000-13030

O-RING (KIT)

33

707-88-22750

BRACKET,L.H.

|$43

707-88-22760

BRACKET,R.H.

34

707-88-21490

BAND

35

01435-01030

BOLT

36

07283-22738

CLIP

37

01599-01011

NUT

38

01643-31032

WASHER

39

707-88-33030

CAP

40

07371-30640

FLANGE,SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$54

707-99-50620

SERVICE KIT
