Запчасти Komatsu PC220LC-7 ЦИЛИНДР КОВША (СИСТЕМА СМАЗКИ 100 ЧАС.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS220

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0H430

CYLINDER ASS'Y

1

707-13-14570

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-10710

ROD,PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL,DUST (KIT)

7

707-27-14930

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD (KIT)

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING,BACK-UP (KIT)

14

707-51-10640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-14650

PISTON

18

707-44-14180

RING,PISTON (KIT)

19

707-39-14110

RING,WEAR (KIT)

20

707-44-14910

RING

21

07001-05090

RING,BACK-UP (KIT)

22

07000-15090

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

707-86-66390

TUBE

27

07372-21060

BOLT

28

01643-51032

WASHER

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT)

32

707-88-22680

BRACKET

33

707-88-21361

BAND

34

07372-21035

BOLT

35

01643-51032

WASHER

36

07283-32738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

39

707-88-33030

CAP

40

07371-30640

FLANGE,SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$47

707-99-58060

SERVICE KIT
