Запчасти Komatsu PC220LC-7 ЦИЛИНДР КОВША (СИСТЕМА СМАЗКИ 100 ЧАС.) (СПЕЦ-Я -40С)(№78-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G1

707-01-XP590

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0K670

CYLINDER ASS'Y

1

707-13-13880

CYLINDER

2

707-76-80010

BUSHING

3

07145-10080

SEAL,DUST (KIT)

4

707-58-90F30

ROD,PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL,DUST (KIT)

7

707-27-13750

HEAD,CYLINDER

8

707-88-05870

COLLAR

9

707-56-90740

SEAL,DUST (KIT)

10

707-52-90681

BUSHING

11

707-75-90110

RING,SNAP

12

707-51-90730

U-PACKING,ROD

13

07000-55120

O-RING (KIT)

14

707-35-91320

RING,BACK-UP (KIT)

15

707-51-90650

RING,BUFFER (KIT)

16

01010-81800

BOLT

17

707-41-11840

WASHER

18

707-36-13780

PISTON

19

707-44-13180

RING,PISTON (KIT)

20

707-39-13150

RING,WEAR (KIT)

21

707-44-13911

RING

22

707-35-90940

RING,BACK-UP (KIT)

23

07000-55080

O-RING (KIT)

24

01310-01216

SCREW

25

07020-00000

FITTING,GREASE

26

07020-00000

FITTING,GREASE

27

707-88-05880

PLATE

28

707-88-03921

RING

29

707-56-90820

SEAL,DUST (KIT)

30

01011-81805

BOLT

31

707-41-11840

WASHER

32

700-11-31980

PLATE, NAME

33

707-86-67820

TUBE

34

07372-21060

BOLT

35

01643-51032

WASHER

36

07372-21045

BOLT

37

01643-51032

WASHER

38

07000-53030

O-RING (KIT)

39

707-88-22640

BRACKET

40

707-88-21331

BAND

41

07372-21035

BOLT

42

01643-51032

WASHER

43

07283-32738

CLIP

44

01597-01009

NUT

45

01643-31032

WASHER

|$53

707-99-47851

SERVICE KIT
