Запчасти Komatsu PC220LC-7 ЦИЛИНДР КОВША ( ЧАС. СИСТЕМА СМАЗКИ)(№889-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XU581

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0G492

CYLINDER ASS'Y

1

707-13-13611

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-90940

ROD,PISTON

5

707-76-80020

BUSHING

6

20Y-70-23230

SEAL,DUST (KIT)

7

707-27-13750

HEAD,CYLINDER

8

07179-13104

RING,SNAP

9

195-63-94170

SEAL,DUST (KIT)

10

707-52-90680

BUSHING

11

707-51-90030

PACKING,ROD (KIT)

12

07000-15120

O-RING (KIT)

13

707-35-91320

RING,BACK-UP (KIT)

14

707-51-90640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-13780

PISTON

18

707-44-13180

RING,PISTON (KIT)

19

707-39-13150

RING,WEAR (KIT)

20

707-44-13911

RING

21

707-35-90940

RING,BACK-UP (KIT)

22

07000-15080

O-RING (KIT)

23

01310-01216

SCREW

24

07020-00000

FITTING,GREASE

25

07020-00900

FITTING,GREASE

26

707-75-90110

RING,SNAP

27

707-86-66350

TUBE

28

01435-01055

BOLT

29

01435-01040

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT)

32

707-88-22640

BRACKET

33

707-88-21331

BAND

34

07372-21035

BOLT

35

01643-51032

WASHER

36

07283-22738

CLIP

37

01597-01009

NUT

38

01643-31032

WASHER

39

707-88-33030

CAP

40

07371-30640

FLANGE

41

07372-21035

BOLT

42

01643-51032

WASHER

|$47

707-99-47570

SERVICE KIT
