Запчасти Komatsu PC220LC-7 ЦИЛИНДР РУКОЯТИ(№77-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ902

CYLINDER,(FINAL COATING)

G-1

707-01-XZ902

CYLINDER,(FINAL COATING)

|$5

707-01-0A372

CYLINDER ASS'Y

1

707-13-14550

CYLINDER

2

707-76-80560

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-10681

ROD,PISTON

5

707-27-14930

HEAD,CYLINDER

6

07179-13114

RING,SNAP

7

176-63-56170

SEAL,DUST (KIT)

8

707-52-90780

BUSHING

9

707-51-10030

PACKING,ROD (KIT)

10

07000-15130

O-RING (KIT)

11

707-35-91420

RING,BACK-UP (KIT)

12

707-51-10640

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-14650

PISTON

16

707-44-14180

RING,PISTON (KIT)

17

707-39-14110

RING,WEAR (KIT)

18

707-44-14910

RING

19

707-71-61080

PLUNGER

20

07000-15090

O-RING (KIT)

21

07001-05090

RING,BACK-UP (KIT)

22

01310-01216

SCREW

23

707-71-70270

PLUNGER

24

07020-00000

FITTING,GREASE

25

707-71-32780

COLLAR

26

707-35-91420

RING,BACK-UP (KIT)

27

07000-15130

O-RING (KIT)

28

04260-00635

BALL

29

707-71-91270

CAP

30

707-83-13010

VALVE

31

07750-01628

SPRING

32

707-87-14070

PLUG

33

07002-12034

O-RING (KIT)

34

707-86-66340

TUBE

35

20D-62-17860

ELBOW

36

07372-21060

BOLT

37

07372-21045

BOLT

38

01643-51032

WASHER

39

07000-13030

O-RING (KIT)

40

01010-81080

BOLT

41

01643-31032

WASHER

42

07000-13035

O-RING (KIT)

43

707-88-22630

BRACKET

44

707-88-21321

BAND

45

07372-21035

BOLT

46

01643-51032

WASHER

47

707-88-11560

PLATE

48

07283-32738

CLIP

49

01597-01009

NUT

50

01643-31032

WASHER

|$57

707-99-58070

SERVICE KIT
