Запчасти Komatsu PC220LC-6Z ЦИЛИНДР СТРЕЛЫ(ПОДЪЕМ СПЕЦ-Я.)(№-8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

206-63-X2801

BOOM CYLINDER GROUP,L.H.

G-2

206-63-X2811

BOOM CYLINDER GROUP,R.H.

|$5

206-63-02801

CYLINDER ASS'Y

1

206-63-54541

CYLINDER

2

206-70-55280

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

206-63-54520

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-14640

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST (KIT)

10

707-52-90750

BUSHING

11

707-51-10030

PACKING,ROD (KIT)

12

07000-15135

O-RING (KIT)

13

07001-05135

RING,BACK-UP (KIT)

14

707-51-10630

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-14360

PISTON

18

707-44-14180

RING,PISTON (KIT)

19

707-39-14820

RING,WEAR (KIT)

20

707-44-14910

RING

21

707-71-61011

PLUNGER

22

07165-16870

NUT

23

707-71-32760

COLLAR

24

07001-05135

RING,BACK-UP (KIT)

25

07000-15135

O-RING (KIT)

26

206-63-54571

TUBE,L.H.

26

206-63-54671

TUBE,R.H.

27

206-63-54580

TUBE,L.H.

27

206-63-54680

TUBE,R.H.

28

07372-21060

BOLT

29

07372-21045

BOLT

30

01643-51032

WASHER

31

07000-13030

O-RING (KIT)

32

206-63-54590

BRACKET,L.H.

32

206-63-54690

BRACKET,R.H.

33

707-88-87680

BAND

34

01010-51035

BOLT

35

01643-51032

WASHER

36

07283-22738

CLIP

37

01599-01011

NUT

38

01643-31032

WASHER
