Запчасти Komatsu PC220LC-6Z ГУСЕНИЦЫ () (MM ШИР.) ХОДОВАЯ

Схема запчастей Komatsu PC220LC-6Z - ГУСЕНИЦЫ () (MM ШИР.) ХОДОВАЯ
1
2
3
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
19
19
19
20
20

Артикул

Название

Примечание

Количество

|$4

206-32-03231

TRACK SHOE ASS'Y

|$5

206-32-03230

TRACK SHOE ASS'Y

1

20Y-32-11123

LINK,TRACK, L.H.

2

20Y-32-11133

LINK,TRACK, R.H.

3

20Y-32-11240

SEAL,DUST, REGULAR, W-TYPE

4

20Y-32-11171

BUSHING,MASTER

4

20Y-32-11170

BUSHING, MASTER

5

20Y-32-11141

BUSHING,REGULAR

5

20Y-32-11140

BUSHING, REGULAR

6

20Y-32-11150

PIN, REGULAR

7

20Y-32-11350

SHOE,TRACK

8

20Y-32-11220

BOLT (Y0320-K02

9

154-32-31220

NUT, SHOE (Y0320-K02

10

20Y-32-11123

LINK,TRACK, L.H.

11

20Y-32-11133

LINK,TRACK, R.H.

12

20Y-32-11240

SEAL,DUST, REGULAR, W-TYPE

13

20Y-32-11171

BUSHING,MASTER

13

20Y-32-11170

BUSHING, MASTER

14

20Y-32-11141

BUSHING,REGULAR

14

20Y-32-11140

BUSHING, REGULAR

15

20Y-32-11150

PIN, REGULAR

16

20Y-32-11350

SHOE,TRACK

17

20Y-32-11220

BOLT (Y0320-K02

18

154-32-31220

NUT, SHOE (Y0320-K02

19

20Y-32-11260

SEAL,DUST, MASTER, W-TYPE

20

20Y-32-11190

PIN, MASTER

Выбрано товаров: 26
