Запчасти Komatsu PC220LC-6Z КАБИНА (ПЕРЕДН. ОКНА) (С ПРОЗРАЧН. КРЫША)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$4

20Y-54-37302

FRONT WINDOW ASS'Y

|$5

20Y-54-37301

FRONT WINDOW ASS'Y

|$6

20Y-54-37300

FRONT WINDOW ASS'Y

1

201-54-73892

FRONT WINDOW

1

201-54-73891

FRONT WINDOW

1

201-54-73890

FRONT WINDOW

2

20Y-54-37651

GLASS

2

20Y-54-37650

GLASS

3

20Y-54-38132

WEATHER STRIP

3

20Y-54-38131

WEATHER STRIP

4

20Y-54-38142

SEAL

4

20Y-54-38141

SEAL

5

20Y-54-38152

SEAL

6

20T-54-75270

LATCH ASS'Y,L.H.

7

20T-54-75280

LATCH ASS'Y,R.H.

8

01435-30816

BOLT

9

20Y-54-14290

STOPPER

9

20Y-54-14290

STOPPER

10

01580-11008

NUT

10

01580-11008

NUT

11

20Y-54-14590

HANDLE

12

01023-10616

SCREW

13

20Y-54-14310

STRIKER

14

20Y-54-14280

SCREW

15

20Y-54-37810

STOPPER

16

01023-70416

SCREW

17

20Y-54-37820

STOPPER

18

01023-70416

SCREW

19

20Y-54-36834

BLOCK,L.H.

19

20Y-54-36833

BLOCK,L.H.

20

20Y-54-36844

BLOCK,R.H.

20

20Y-54-36843

BLOCK,R.H.

21

01252-50635

BOLT

22

01641-50608

WASHER

23

20Y-54-39152

ROLLER

23

20Y-54-39151

ROLLER

24

205-54-63310

LOCK ASS'Y

25

01435-30820

BOLT

26

201-54-73180

BRACKET

27

01435-30820

BOLT

28

154-61-16570

WASHER

29

20Y-54-14721

LOCK

30

01435-30820

BOLT

|$51

20Y-54-37601

LOWER WINDOW ASS'Y

|$52

20Y-54-37600

LOWER WINDOW ASS'Y

31

20Y-54-36122

LATCH ASS'Y,R.H.

32

20Y-54-36132

LATCH ASS'Y,L.H.

33

20Y-54-36142

PLATE

34

20Y-54-36191

GROMMET

35

01225-70612

SCREW

36

20Y-54-36211

COVER

37

20Y-54-37611

GLASS

37

20Y-54-37610

GLASS

38

20Y-54-36171

SEAT

39

20Y-54-36230

SHIM, 2.0MM

40

01370-00620

SCREW

41

20Y-54-36182

STOPPER

42

01435-30820

BOLT

43

20Y-979-2281

BRACKET

44

20Y-979-2290

SEAT

45

01435-30830

BOLT
