Запчасти Komatsu PC220LC-6LE FIG NO. A-AA ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ - SADE-

1

6736-51-8720

GASKET, OIL DRAIN

|$1

6735-81-8180

TURBOCHARGER ASSEMBLY

|$2

NSS

TURBOCHARGER

2

1304 920 H1

PLATE, CLAMPING

3

6736-81-8370

BEARING, TURBOCHARGER

4

6731-81-8160

NUT, LOCK - M7-1.00

5

6736-81-8480

SCREW, DRIVE

6

6736-81-8430

SHIELD, TURBOCHARGER HEAT

7

6736-81-8280

SHAFT AND WHEEL

8

6733-81-8360

RING, RETAINING

9

NSS

DATAPLATE

10

6733-81-8330

BAFFLE, OIL

11

6733-81-8460

SEAL, O RING

12

6733-81-8270

PLATE, OIL SEAL

13

6733-81-8260

SLINGER, OIL

14

6735-81-8610

BEARING, THRUST

15

6735-81-8620

COLLAR, THRUST

16

6733-81-8480

PIN, ROLL

17

6735-81-8510

HOUSING, BEARING

18

6735-81-8310

RING, RETAINING

19

6735-81-8530

HOUSING, TURBINE

20

6735-81-8540

IMPELLER, COMPRESSOR

21

6735-81-8270

HOUSING, COMPRESSOR

22

6736-81-8440

SEAL, SPLIT RING

23

6736-81-8320

SEAL, SPLIT RING

24

6736-81-8380

BOLT - M8-1.25 X 12

25

6736-81-8360

RING, RETAINING

26

6736-11-5710

GASKET, TURBOCHARGER MOUNTING
